GigaPan User Guide
15
Turn the EPIC on by pressing the OK button. The first thing you will see is the word
“calibrating.” The robot is checking internal systems at this point. Once this process is
done, the first menu option, ‘New Panorama’, will appear. To navigate to other menu
options, push the down button. To reach submenus within a menu option, push the OK
button once you reach the desired main menu option, then the down button to access
the submenu choices. To exit a menu or submenu, push the X button.
To turn the unit off, hold the OK button down until the word “Goodbye” appears
3.3 Navigating the EPIC Menu
EPIC Menu Tree
New Panorama
360 Panorama
Last Panorama
Options
Time per Pic •
Battery Status •
Start Delay •
Mult. Shutter (EPIC 100 only) •
Factory Reset •
Menu Options Glossary
New Panorama – Sets the upper left photo and the lower right photo that defines the
rectangular area of the panorama.
360 Panorama - Sets the upper pitch and the lower pitch of a panorama that is 360
degrees and completes a full circle.
Last Panorama - The EPIC will use the settings from the most recent panorama
photographed or set up.
Options – Contains submenus that allow you to change more settings.
Time per Pic - The amount of time that the EPIC will wait until it moves the camera. It is
important to allow enough time for the camera to process the current photograph and
move the data to flash memory. This is the most likely reason the camera would miss a
photograph.
Battery status – This option will tell you what the voltage level of the batteries is. A
voltage of 9 volts means that the batteries are fully charged. A voltage of around 7 volts
means your batteries will not be able to operate the EPIC for much longer.
Expert Options
Button Hold
NORMAL
SHORT
Checklist
Shutter Method
Button Pusher
Remote Port (EPIC 100 only)
Manual
Pic Ordering
Column
Row – down
Row – up
Motors On
Backlight Mode
Firmware Ver
Gigapan Setup
Current FOV
Set up camera Field of View?
