Evolution Engines EVOE20GX - Manual (Page 16)

EN
16
Parts List
# Description part
1 Cylinder Screw (6) EVO120123
2 Spark Plug EVOG10350
3 Cylinder Head EVOG20103
4 Cylinder Head Gasket (2) EVO120112
5 Cylinder EVOG20202
6 Piston Ring EVO120236
7 Ringed Piston EVOG20214R
8 Piston Pin & Retainer EVO120213
9 Connecting Rod EVOG20204
10 Prop Washer & Nut EVO100228
11 Drive Washer EVOG20219
12 Spacer Washer EVO91225
13 Front Bearing EVO91109
14 Crankcase EVOG20101
15 Rear Bearing EVO400110
16 Drive Key EVO91218
17 Crankshaft EVOG20210
18 Back Cover Set EVOG20102
19 Back Cover Screw EVO61122
20 Muffler Assembly EVOG20601
21 Complete Ignition System EVOG10300
22 In line Fuel Filter EVOA105
23 In Tank Fuel Filter/Clunk EVOA106
# Description part
24 Carburetor Assembly EVOG15801
25 Ignition Sensor Set EVOG10310A
26 Carburetor Gasket Set EVOG15108A
27 Carb Mount Gasket Set EVOG61816A
28 Medium Gas-FKM Fuel
Tubing
EVOA102
29 Muffler Mounting Screw
Set
EVO110E100A
30 Gasket Set EVO120416
31 Muffler Gasket Set EVO100609
32 High-Speed Needle EVOG15829
33 Carb Regulator Screws EVOG12123
34 Carburetor Retainer EVO61119
35 High-Speed Needle
Valve Assmbely
EVOG15812
36 Fuel Nipple EVO100114
37 Regulator Case Parts EVOG1087A
38 Carb Barrel Spring EVOG10814
39 Throttle Arm EVO46866
40 Throttle Barrel EVOG15813
41 Low-Speed Adjustment EVOG15844
42 Main Carb Body EVOG15827
43 Carb Barrel Retaining Bolt EVOG46825
