Isotropic Electric Field Probes
HI-4453/FP5083/FP4083/FP2083
© ETS-LINDGREN L.P. – June 2005
Rev. F, P# H-600064
32
When it completes the command, the probe responds with a
string consisting of
1) A start character (":")
2) The command letter, followed by
3) Data, if required, and terminated with
4) A carriage return.
If the command does not require the probe to return any data,
the probe simply responds with the command letter and a
carriage return. If an error occurs, the probe responds with an
error code, as detailed in Appendix A.
COMMANDS
Command Description
Axxx Axis enable/disable. x = "E" means enable, x =
"D" means disable. xxx order is X axis, Y axis, Z
axis
B Read battery voltage.
Cx Set baud rate.
x = 1 sets rate to 2400 baud
x = 2 sets rate to 9600 baud
New baud rate does not take effect until the next
power-up.
Dx Read probe data.
x = 1 enables short form output
x = 2 enables long form output
Lx Load table data.
x = ASCII hex data
Rx Set range.
x = 1, 2, 3, 4 or N (next range)
Sx Sleep timer.
x = number of seconds to wait for a command
before putting the probe into the sleep mode.
Tx Read Temperature.
x = C or F
Ux Set unit type.
x = 1, 2, 3, or N (next unit)
1 = V/m
2 = mW/cm²
3 = [V/m]²
Archived 4/2/10
