ETS-Lindgren 3142B BiConiLog Antenna (Archived) - Manual (Page 20)

Specifications MODEL 3142B BICONILOG™ ANTENNA
SPECIFICATIONS
ELECTRICAL
3142B
With Standard Bow-tie
Elements With Optional End Plates
Frequency
Range
26-2000 MHz
26-2000 MHz
Input
Impedance
50 ς 50 ς
VSWR
2:1 average 2:1 average
CW power
1 kW, above 100 MHz
300 W, below 100 MHz 1 kW, above 60 MHz
500 W, below 60 MHz
Symmetry
+/- 0.5 dB +/- 0.5 dB
Connector N female N female
PHYSICAL
3142B
With Standard
Bow-tie Elements With Optional
End Plates
Height (bow-tie)
75 cm
29.5 in
75 cm
29.5 in
Width (bow-tie)
135 cm
53.1 in
136 cm
53.5 in
Depth (boom length)
90 cm
35.4 in
132 cm
51.9 in
Weight 4 kg
8.8 lb
6.8 kg
14.9 lb
