ETS-Lindgren 3142B BiConiLog Antenna (Archived) - Manual (Page 16)

Typical Data without the End Plates MODEL 3142B BICONILOG™ ANTENNA
10 100 1,000
MHz
-30
-25
-20
-15
-10
-5
0
5
10
dBi
1 m
3 m
10 m
Figure 3. Model 3142B Typical Gain
10 100 1,000
MHz
0.001
0.01
0.1
1
10
100
1,000
W
1 m
3 m
Figure 4. Model 3142B Typical 1 V/m Power Required
12
© EMC TEST SYSTEMS, L.P. – MARCH 2002
REV C – PN 399229
Archived 09/23/10
