MODEL 3142B BICONILOG™ ANTENNA Typical Data with the End Plates
20 30 40 50 60 70 80
MHz
0.1
1
10
100
1000
W
1 V/m
3 V/m
10 V/m
3 V/m 80% AM
Figure 3. Model 3142B typical 1 m forward power.
20 30 40 50 60 70 80
MHz
0.1
1
10
100
1000
W
1 V/m
3 V/m
10 V/m
Figure 4. Model 3142B typical 3 m forward power.
© EMC TEST SYSTEMS, L.P. – MARCH 2002
15
REV C – PN 399229
