MODEL 3142B BICONILOG™ ANTENNA Typical Data without the End Plates
10 100 1,000
MHz
1
10
100
VSWR
Figure 1. Model 3142B Typical VSWR
0 200 400 600 800 1,000 1,200 1,400 1,600 1,800 2,000
MHz
5
10
15
20
25
30
35
dB[1/m]
1 m
3 m
10 m
Figure 2. Model 3142B Typical Antenna Factor
