www.ets-lindgren.com Electrical Specifications 13
3.0 Electrical Specifications
Model 7405
Primary
Sensor Type
E/H or H/E
Rejection
Upper
Resonant
Frequency
901
6-cm loop
H-Field 41 dB 790 MHz
902
3-cm loop
H-Field 29 dB 1.5 GHz
903
1-cm loop
H-Field 11 dB 2.3 GHz
904
3.6-cm ball
E-Field 30 dB >1 GHz
905
6-mm stub tip
E-Field 30 dB >3 GHz
Preamplifier
Absolute Maximum Ratings:  Input Voltage (DC): 12 VDC
 Input Voltage (AC): +20 dBm
Bandwidth: 100 kHz –3 GHz
Noise Figure
(Ref. 50 ohms):
3.5 dB (typical)
Saturated Output Power
(at F = 100 MHz):
+12.0 dBm
1 dB Gain Compression
(at F = 100 MHz):
+10.0 dBm
Third Order Intermodulation
Intercept:
+23 dBm
