The Model 4825/2 is nominally designed for a 25-ampere current capacity. For
safe operation, you must follow the maximum current rating of the output
receptacle on the mains power adapter. See Specifications on page 11 or the
back panel of the Model 4825/2 for the applicable current rating.
Maximum line-to-line voltage must not exceed the voltage rating of the power
connectors provided on the input and output of the unit. See Specifications on
page 11 for the applicable maximum value.
The input power connection to the line side of the Model 4825/2 is made through
the IEC-309 pin and sleeve type power inlet on the back panel. This three-wire
power inlet is rated at 125/250 VAC 60 Hz in North America. Additionally, the
power inlet is certified by VDE for operation at 220-240 VAC 50 Hz. Power to the
Model 4825/2 is routed directly from the power inlet to an internally-wired
25 ampere circuit breaker. This circuit breaker provides a means to remove
power in case of emergency.
An IEC-309 cable mount connector is provided with the Model 4825/2. This
connector is a three-wire receptacle rated at 32 amperes. The cordage required
to connect the power mains to the unit must meet certain regulatory requirements
for electrical safety. A harmonized metric cordage size of 3 x 4.00 mm
2
is
recommended for international applications. A wire size of 8 AWG is
recommended for installation in North America. The installation wiring of the
Model 4825/2 should be accomplished by an electrician authorized to do such
work by appropriate code or law. The following color codes should be observed:
North America International
125 VAC 250 VAC
Line – Black Line – Brown
Neutral – White Neutral – Blue
Ground – Green or Green/Yellow Earth – Green/Yellow
Installation | 15
