Page 16
16
Installation and Application
www.ets-lindgren.com
Back Panel Connectors
P
OWER
I
NPUT
The input power connection is made through a jacketed three-conductor power
cable. This three-conductor power cable is rated at 16 amperes maximum. In
case of emergency, power can be removed from the unit by disconnecting the
Model 3816/2 input power plug from the power mains. Alternately, a properly
rated circuit breaker or switch which removes mains power from the unit can be
installed in proximity to the unit.
RF
G
ROUND
See description on page 14.
