14 Installation and Application www.ets-lindgren.com
The input power connection is made through a three-wire power cord utilizing the
accepted international color code. The input power cord opening is sized to
accept a standard electrical conduit fitting or strain relief (supplied). An
internally-mounted terminal strip provides the input connection point. When
connecting the conduit, disconnect the power cord from the terminal strip and
remove it.
Front Panel Connectors and Controls
BNC C ONNECTOR
Connect the Model 3816/2 to the spectrum analyzer or EMI receiver through the
BNC connector.
RF G ROUND
The Model 3816/2 is provided with an RF bonding stud on both the front and rear
panels. The unit should be bonded to a ground plane in normal operation.
E ARTH L INE C HOKE S WITCH
The safety ground isolation choke selector switch switches the 1.6 mH earth line
choke IN and OUT of the safety ground circuit. The ground choke is designed
and manufactured with sufficient capacity to conduct the maximum current rating
of the Model 3816/2 and at no time is the safety ground of the unit compromised.
The earth line choke avoids a double RF ground connection (safety ground and
measurement ground) in the conducted emissions test setup.
A RTIFICIAL H AND
In conformance with EN55014 and BS800, the artificial hand connection is used
to test handheld equipment that is provided without earth connections.
