ETS-Lindgren 3301C Active Monopole - Manual (Page 37)

O UTPUT C ONNECTOR
Plug a 50-ohm BNC cable into this connector. Connect the other end of the cable
to the required monitoring equipment.
P OWER LED
See page 42 for the steps to charge the batteries.
State of LED Indicates
Green, steady Power is on.
Green, blinking Batteries are low.
Data produced in this condition may be invalid. Suspend
testing and charge the batteries.
No light (off) Unit is in shut off mode.
If the unit is switched on and the power LED is off, the
batteries may be depleted. Charge or replace the
batteries.
P OWER S WITCH
The power switch operates as an on/off switch for Model 3301C and the battery
charging function. When you are using the Model 3301C, the switch should be
set to ON. When the Model 3301C is off or you are charging the batteries, the
switch should be set to OFF/CHG.
Operation | 37
