Saturation Indicator
Impulse Response:
The saturation indicator will properly
indicate saturation for pulsed signals which
fall within the following boundaries:
• The product of the pulse width to pulse
repetition rate must be greater than
0.003.
• The pulse repetition rate must be less
than value listed for the applicable duty
cycle. See the following Table of
Acceptable Pulse Repetition Rates .
T ABLE OF A CCEPTABLE P ULSE R EPETITION R ATES
Duty Cycle Maximum PRF
10 19.7 MHz
20 14.0 MHz
30 9.2 MHz
40 5.6 MHz
50 420.0 kHz
60 130.0 kHz
70 87.0 kHz
80 57.0 kHz
90 30.0 kHz
