3.0 Specifications
Operational Specifications
Frequency Range: 30 Hz to 50 MHz
(maximum usable bandwidth)
Low Frequency Roll Off: The low frequency roll off is
switch-selectable to be 3 dB down at
22 kHz, 1.9 kHz, or 170 Hz.
High Frequency Roll Off: Antenna factor is 3 dB down at 30 MHz
Antenna Factor: • See data chart on page 54.
• Unless otherwise noted, the low
frequency roll off is set at the 170 Hz
3 dB roll off point
Saturation Level: • 0.8 V/m narrowband without attenuation
• 25 V/m with 30 dB of internal attenuation
selected
• 63 dBuV/m/MHz broadband saturation
level
Minimum Discernible
Signal:
• See data chart on page 56.
• For best sensitivity all internal
attenuation should be turned off
Dynamic Range: • 111 dB at mid-band (1 MHz)
• 141 dB with the use of the internal
attenuators
