Model 3164-06, Model 3164-08 – ETS-Lindgren 3164-10 Open Boundary Quad-Ridged Horn User Manual
Page 20
20
Specifications
www.ets-lindgren.com
M
ODEL
3164-06
Frequency Range:
300 MHz–6 GHz
Max VSWR:
< 6.5:1
Gain over Operating
Frequency:
See Gain data on page 67
Maximum Continuous Power:
150 W at 300 MHz
25 W at 6 GHz
Impedance (Nominal):
50 Ω
Connector:
SMA (2) female
Cross Polarization Isolation:
> 25 dB
Dual Polarization Symmetry:
See Gain data on page 67
M
ODEL
3164-08
Frequency Range:
700 MHz–10 GHz
Max VSWR:
< 3:1
Gain over Operating
Frequency:
See Gain data on page 77
Maximum Continuous Power:
100 W at 700 MHz
20 W at 10 GHz
Impedance (Nominal):
50 Ω
Connector:
SMA (2) female
Cross Polarization Isolation:
> 20 dB
Dual Polarization Symmetry:
See Gain data on page 77
