ETS-Lindgren 3160 Pyramidal Standard Gain Antenna User Manual
Page 41
www.ets-lindgren.com
Typical Data
41
3160-03
3160-04
3160-05
3160-06
Frequency
G
Frequency
G
Frequency
G
Frequency
G
1.7
14.34
2.6
14.811
3.95
14.9746
5.85
15.6617
1.88
15.1526
2.87
15.6315
4.33
15.7343
6.32
16.2986
2.06
15.8791
3.14
16.371
4.71
16.4232
6.79
16.8847
2.24
16.5331
3.41
17.0425
5.09
17.09
7.26
17.4266
2.42
17.1247
3.68
17.6558
5.47
17.6294
7.73
17.9293
2.6
17.6622
3.95
18.2182
5.85
18.161
8.2
18.3973
3160-07
3160-08
3160-09
3160-10
Frequency
G
Frequency
G
Frequency
G
Frequency
G
8.2
15.0692
12.4
14.8536
18
14.9048
26.5
15.0323
9.04
15.8748
13.52
15.5532
19.7
15.9601
29.2
15.7974
9.88
16.6011
14.64
16.1886
21.4
16.2776
31.9
16.4806
10.72
17.2604
15.76
16.7687
23.1
16.8683
34.6
17.0941
11.56
17.8623
16.88
17.3006
24.8
17.4065
37.3
17.6474
12.4
18.4142
18
17.7898
26.5
17.8984
40
18.148
