Table of Contents
Notes, Cautions, and Warnings .............................................. vii
1.0 Introduction .......................................................................... 9
Tripod Options .......................................................................................... 11
ETS-Lindgren Product Information Bulletin ............................................... 12
2.0 Maintenance ....................................................................... 13
Annual Calibration .................................................................................... 13
Service Procedures .................................................................................. 14
3.0 Specifications ..................................................................... 15
Electrical Specifications ............................................................................ 15
Model 3160 Series ............................................................................ 15
Model 3160-u5 and Model 3160-u7: Standard Gain Horns
Below 1 GHz ..................................................................................... 15
Model 3160-u5 .......................................................................... 16
Model 3160-u7 .......................................................................... 17
Physical Specifications ............................................................................. 19
Model 3160 Series ............................................................................ 19
Model 3160-u5 and Model 3160-u7: Standard Gain Horns
Below 1 GHz ..................................................................................... 20
Model 3160-u5 .......................................................................... 20
Model 3160-u7 .......................................................................... 25
4.0 Mounting Instructions ....................................................... 31
3160-09 and 3160-10 Only ....................................................................... 32
3160-09 ............................................................................................ 32
3160-10 ............................................................................................ 32
Mount to 4-TR ........................................................................................... 33
Mount to 7-TR and Mast ........................................................................... 34
Mount to 2x2 Boom ................................................................................... 35
5.0 Typical Data ........................................................................ 37
Typical VSWR (3160-06) .......................................................................... 37
Typical Gain and Antenna Factor (3160-06) .............................................. 38
