Typical Data

37

5.0 Typical Data

Following is typical electromagnetic performance data for the Model 3160 Series
Pyramidal Horn Antenna, using Model 3160-06 data as representative of the
series. See Model 3160 Series Data on page 61 for data for all
Model 3160 Series antennas.

Typical VSWR (3160-06)

The following shows the antenna/coax-to-waveguide adapter assembly.
