Dynojet 250ix: Extended Carriage and Trike Adapter Assembly User Manual
Page 5
Extended Carriage with Trike Adapter Assembly Installation Guide
1
E
XTENDED
C
ARRIAGE
WITH
T
RIKE
A
DAPTER
A
SSEMBLY
I
NSTALLATION
This document provides instructions for installing the extended carriage with the
trike adapter assembly on the model 200iX and 250iX motorcycle dynamometers
(dyno). To ensure safety and accuracy in the procedures, perform the procedures as
they are described.
Document Part Number: 98200016
Version 2
Last Updated: 02-07-12
