GigMAC PMC and PCI Board and Driver Users Manual
10.3 DPM DRIVER MANAGEMENT API
The dpm network driver management API is an api extension primarily used by
the ‘dmUtil’ command line utility to enable various management functions or to
acquire driver status and statistics. The typical api usage sequence is as follows:
1. User enters ‘dmUtil’ command and parameters as shown in the following
example:
./dmUtil –s eth1
2. dmUtil parses command line and prepares an “ioctl” request block to send
to driver. A pointer to a application buffer to hold the text message results
(for example formatted statistics) is provided by dmUtil in the request
block.
3. Driver receives ioctl request block performs action and copies result data
to applications message buffer.
The following is an API description of the management ioctl commands issued to
the driver from the ‘dmUtil’ application’s viewpoint:
A. Opening a socket for management API
int s;
s = socket (PF_INET, SOCK_STREAM, 0);
B. Create request block for driver ioctl
struct ifreq ifr;
int subCmd;
NpkUserCtl myIoc;
char myDataBuf[MAX_LINES * MAX_LINE_LEN];
/* set interface name */
strcpy (ifr.ifr_name, “eth1”);
/* set ioctl sub-type */
subCmd = DM_IOCTL_GET_STATS;
/* set command argument */
myIoc.arg1 = 0;
myIoc.dataItm = (u_int) myDataBuf;
ifr.ifr_data = (char *) &myIoc;
