TEC520_TEC520C_TEC728 - Version D - Released July 31, 2014 - Copernicus Educational Products Inc.
1/4” X 3”
Bolt
4x A
1
You will need:
(Not to Scale)
Actual Size:
Cross Stretcher
2x Main Frame - Back
1x
Install Cross Stretcher & Stretchers to
Main Frame - Back
2
You will need:
(Not to Scale)
Actual Size:
Install the Main Frame - Front
A
B
1/4” Lock Washer
4x B
Main Frame - Front
1x
2-Person Task
2-Person Task
A
Hand tighten bolts ONLY
Open the doors to the side while
assembling the frame.
Note the tabs on the
Main Frame - Back
1/4” X 3”
Bolt
4x A
A
Hand tighten bolts ONLY
7
