You will need:
(Not to Scale)
Actual Size:
Install the Shelves
(Repeat this step for all 4 shelves)
1
Hook the back tabs around the Main Frame - Back
2
Rotate and hook the front tab around the
Main Frame - Front
F
R
O
N
T
V
IE
W
B
A
C
K
V
IE
W
3
Secure the shelf in place using two Tree Clips
F
R
O
N
T
V
IE
W
Value-Line Tree Clip
8x G
G
Shelf
4x
Press Tree Clips firmly into
Main Frame - Front stretcher.
Tap the Tree Clips in using a
rubber mallet.
