Place the inner tube inside the outer tube, Assemble the outer tube to the base – Copernicus DCS1 User Manual
Page 6
DCS1 - Version D - 9 September 2014 - Copernicus Educational Products Inc.
1
You will need:
(Not to Scale)
Actual Size:
2
Place the Inner Tube inside the Outer Tube
You will need:
(Not to Scale)
Actual Size:
Outer Tube
1x
Base
1x
Pay close attention to the
orientation of the Valco
Double-End Snap Buttons.
Inner Tube
Pre-Assembly
1x
Make sure the stop hole is
facing inwards and is placed
on top.
Assemble the Outer Tube to the Base
A
A
M6 x 20mm
1x
6
