Step 5,6, Install chart caddy stretcher, Install telescoping arms & knobs – Copernicus BTHC1 User Manual
Page 6
BTHC1 - Version B - Released 1 July 2012 - Copernicus Educational Products Inc.
5
Install Chart Caddy Stretcher
You will need:
(Not to Scale)
Actual Size:
You will need:
(Not to Scale)
Actual Size:
Chart Caddy Stretcher
1x
M6x35mm Bolt
x 2
M6 Lock Washer
x 2
Telescoping Arms (left & right)
1x
Knob
2x
Install Telescoping Arms & Knobs
A
C
Note the hooks face
the back of unit
Tightening the knobs will
stop the arms from sliding.
Loosen knobs to adjust.
C
A
A
C
Note the orientation of bend is
toward the front of unit
6
