Step 3,4, Install back frame, Install casters – Copernicus BTHC1 User Manual
Page 5
BTHC1 - Version B - Released 1 July 2012 - Copernicus Educational Products Inc.
3
Install Back Frame
You will need:
(Not to Scale)
Actual Size:
4
You will need:
(Not to Scale)
Actual Size:
M6 Lock Washer
x 4
M6x35mm Bolt
x 4
Install Casters
Press Casters firmly into the Base:
?
Casters will click into place
?
If necessary, tap the caster in using a
rubber mallet.
2” Twin Wheel Caster with Brake
4x
A
C
Back Frame
1x
A
C
