4
Attach Built Frame to Plastic Top
Align Legs Assembly with holes in the Plastic Top Assembly
x 4 x 4
Actual Size:
A B
x 4
C
Use 4 holes shown
5
Install Casters
Flip entire Assembly onto its side, so the bottoms of the Legs are exposed
Press Casters firmly into the Legs
- Casters will click into place
- If necessary, place a wrench between the wheels & tap in with a rubber mallet.
Caster x 4
You will need:
(Not to Scale)
AUD1_3_4 - Version A - 15 July 2013 - Copernicus Educational Products Inc.
