2
The use of this or any warning device does not ensure that all drivers can or will observe or react to an
emergency warning signal. Never take the right-of-way for granted. It is your responsibility to be sure
you can proceed safely before entering an intersection, driving against traffic, responding at a high rate of
speed, or walking on or around traffic lanes.
The effectiveness of this warning device is highly dependent upon correct mounting and wiring. Read and
follow the manufacturer’s instructions before installing or using this device. The vehicle operator should
insure daily that all features of the device operate correctly. In use, the vehicle operator should insure the
projection of the warning signal is not blocked by vehicle components (i.e.: open trunks or compartment
doors), people, vehicles, or other obstructions.
This equipment is intended for use by authorized personnel only. It is the user’s responsibility to
understand and obey all laws regarding emergency warning devices. The user should check all
applicable city, state and federal laws and regulations.
Code 3, Inc., assumes no liability for any loss resulting from the use of this warning device.
Proper installation is vital to the performance of this warning device and the safe operation of the
emergency vehicle. It is important to recognize that the operator of the emergency vehicle is under
psychological and physiological stress caused by the emergency situation. The warning device should
be installed in such a manner as to: A) Not reduce the output performance of the system, B) Place the
controls within convenient reach of the operator so that he can operate the system without losing eye
contact with the roadway.
Emergency warning devices often require high electrical voltages and/or currents. Properly protect and
use caution around live electrical connections. Grounding or shorting of electrical connections can cause
high current arcing, which can cause personal injury and/or severe vehicle damage, including fire.
PROPER INSTALLATION COMBINED WITH OPERATOR TRAINING IN THE PROPER USE OF
EMERGENCY WARNING DEVICES IS ESSENTIAL TO INSURE THE SAFETY OF EMERGENCY
PERSONNEL AND THE PUBLIC.
wARNINg!
Unpacking & Pre-installation
After unpacking the items, carefully inspect the unit and its associated parts for any damage that may have been caused in transit.
Report any damage to the carrier immediately.
Installation & Mounting
The TriCore® and Torus™ NarrowStik™ were designed with a flexible mounting system to allow its use with as many light bars as pos-
sible. Figure-1 below shows the mounting bracket assembly that allows the NarrowStik to be attached to most light bar systems. Ques-
tions about a specific application should be directed to the Technical Hot Line number given on the last page of this manual.
Permanent Mounting
Prior to mounting, consideration must be given to cable location. The cable should exit the end cap on the
Driver's side unless otherwise specified.
Introduction
The TriCore ® and Torus ™ NarrowStik ™ are traffic directing devices that will mount in many locations including the back of a light bar or
rear panel of a truck. The NarrowStik Product is a series of lights that point traffic away from the scene of an accident or work site.
FIgURE 1
MOUNTING BRACKET
1/4" FLAT WASHER
1/4" SPLIT WASHER
1/4"-20 ACORN NUT
1/4"-20 X 1/2" LG
CARRIAGE BOLT
