Code 3 LED PriZm II Perimeter Lights - Manual (Page 7)

7
5.750"
3.250"
1.000
0.250
2.875
1.625
1.000
Installation Template Dimensions
Figure 4 - 3x7
Figure 5 - 4x6
Figure 6 - 7x9
7.250"
5.250"
0.250
1.000
2.625"
3.625"
1.000
Maintenance
The lens is field removable for cleaning and replacement. Remove the lens by unscrewing the four mounting
screws. Use mild detergent, warm water and a soft cloth to clean both surfaces of the lens. Use of any other
chemicals may void product warranty. Thoroughly dry before reinstalling.
