Power Requirements CURRENT DRAW
Steady Burn (Peak)
Essex TM Single 6 LED Light Head 0.60 amp average
Essex TM Dual 6 LED Light Head 1.20 amp average when solid flash pattern chosen
Operation
All models are stand alone self-contained units ready for installation with no special wiring required. They are delivered with
a cigarette plug designed to be used with a +12VDC fused lighter socket.
Alternately, the user can remove the plug and connect (through a properly sized fuse) to a user supplied switch.
The ribbed wire is positive (+12VDC) and the smooth wire is negative.
Flash Pattern Selection - Single or Split Head
80FPM Quad Flash, Left/Right (Default)
80FPM Quad Flash, Simultaneous
Steady Burn
75FPM Single Flash, Left/Right
75FPM Single Flash, Simultaneous
150FPM Single Flash, Left/Right
150FPM Single Flash, Simultaneous
75FPM Double Flash, Left/Right
75FPM Double Flash, Simultaneous
150FPM Double Flash, Left/Right
150FPM Double Flash, Simultaneous
75FPM Triple Flash, Left/Right
75FPM Triple Flash, Simultaneous
Each flash pattern can be selected by momentarily depressing the button until the unit stops flashing, and then releasing.
As each flash pattern is selected it is automatically programmed into the unit such that when power is removed it will always
return to the selected pattern the next time power is applied.
Flash Pattern Selection - Dual Head
80FPM Quad Flash, Left/Right (Default)
80FPM Quad Flash, Simultaneous
80FPM Quad Flash, Split Left/Right
80FPM Quad Flash/Solid
Steady Burn
75FPM Single Flash, Left/Right
75FPM Single Flash, Simultaneous
75FPM Single Flash, Split Left/Right
75FPM Single Flash/Solid
150FPM Single Flash, Left/Right
150FPM Single Flash, Simultaneous
150FPM Single Flash, Split Left/Right
150FPM Single Flash/Solid
75FPM Double Flash, Left/Right
75FPM Double Flash, Simultaneous
75FPM Double Flash, Split Left/Right
75FPM Double Flash/Solid
150FPM Double Flash, Left/Right
150FPM Double Flash, Simultaneous
150FPM Double Flash, Split Left Right
150FPM Double Flash/Solid
75FPM Triple Flash, Left/Right
75FPM Triple Flash, Simultaneous
75FPM Triple Flash, Split Left/Right
75FPM Triple Flash/Solid
150FPM Triple Flash, Left/Right
150FPM Triple Flash, Simultaneous
150FPM Triple Flash, Split Left/Right
150FPM Triple Flash/Solid
Explanation of Dual Head Flash Pattern Operation:
Left/Right: Left light head flashes, then right light head flashes (alternating).
Simultaneous: Both light heads flash together.
Split Left/Right: Half of each light head flashes, then the other half of each light head flashes.
Flash/Solid (for California). Half of the light flashes, the other half is in steady burn mode.
5
150FPM Triple Flash, Left/Right
150FPM Triple Flash, Simultaneous
75FPM Quad Pop Flash, Left/Right
75FPM Quad Pop Flash, Simultaneous
150FPM Quad Pop Flash, Left/Right
150FPM Quad Pop Flash, Simultaneous
Modular Flash, Left/Right
Modular Flash, Simultaneous
75FPM Cycle Flash, Left/Right
75FPM Cycle Flash, Simultaneous
150FPM Cycle Flash, Left/Right
150FPM Cycle Flash, Simultaneous
Demo Mode, Left/Right
Demo Mode, Simultaneous
75FPM Quad Pop Flash, Left/Right
75FPM Quad Pop Flash, Simultaneous
75FPM Quad Pop Flash, Split Left/Right
75FPM Quad Pop Flash/Solid
150FPM Quad Pop Flash, Left/Right
150FPM Quad Pop Flash, Simultaneous
150FPM Quad Pop Flash, Split Left/Right
150FPM Quad Pop Flash/Solid
Modular Flash, Left/Right
Modular Flash, Simultaneous
Modular Flash, Split Left/Right
Modular Flash/Solid
75FPM Cycle Flash, Left/Right
75FPM Cycle Flash, Simultaneous
75FPM Cycle Flash, Split Left/Right
75FPM Cycle Flash/Solid
150FPM Cycle Flash, Left/Right
150FPM Cycle Flash, Simultaneous
150FPM Cycle Flash, Split Left/Right
150FPM Cycle Flash/Solid
Demo Mode, Left/Right
Demo Mode, Simultaneous
Demo Mode, Split Left/Right
Demo Mode Flash/Solid
