Parts List
Ref No. Description Part No.
1 Lens T02320 (Green)
T02321 (Clear)
T02322 (Red)
T02323 (Blue)
T02324 (Amber)
2 Filter Half T02262 (Red)
(2 Shown) T02263 (Blue)
T02264 (Amber)
3 Reflector T07001 (Models 80/81)
T09371 (Model 82)
4 Gasket T07006
5 Lamp Assembly (Strobe) T07008
(Halogen) S82110 (12v 50w red dot)
S95285 (12v 65w
Transverse black dot-
For KKK-A-1822E Model 82
only)
S85347 (24v 50w upgrade
puple dot)
S82120 (12v 35w blue dot)
6 Trim Bezel T07002
7 #10 Sheet Metal Screw, 1.75 long T07027
8 Rope Gasket T07005
9 Bezel Gasket (Optional, Not Shown) T03885
