2.
I
NTRODUCTION
Features
• 6-channel DMX-512 LED wide coverage moon flower
• Blackout/static/dimmer/strobe
• Individual control of red, green and blue LEDs within each cluster (7 total)
• Built-in automated programs via master/slave or DMX
• Built-in sound activated programs via master/slave or DMX
• Access built-in programs in master/slave mode via dip switches
Ad d i t i o n a l F e a t u r e s
• Creates
firework-like projections
• Additional power output for daisy chaining units together
• Low-power
consumption
DMX Channel Summary
C
HANNEL
F
UNCTION
1
Operating Mode
2
Cluster 1
3
Cluster 2
4
Cluster 3
5
Cluster 4
6
Cluster 5
7
Cluster 6
8
Cluster 7
9
Strobe
