LED Cluster Values
V ALUE S TATIC C OLORS (S EE BELOW FOR LED DIAGRAM )
132 Щ 135
136 Щ 139
140 Щ 143
144 Щ 147
148 Щ 151
152 Щ 155
156 Щ 159
160 Щ 163
164 Щ 167
168 Щ 171
172 Щ 175
176 Щ 179
180 Щ 183
184 Щ 187
188 Щ 191
192 Щ 195
196 Щ 199
200 Щ 203
204 Щ 207
208 Щ 211
212 Щ 215
216 Щ 219
220 Щ 223
224 Щ 227
228 Щ 231
232 Щ 235
236 Щ 239
240 Щ 243
244 Щ 247
248 Щ 251
252 Щ 255
Red 1
Green 1
Red 1, Green 1
Red 2
Red 1, Red 2
Red 2, Green 1
Red 1, Green 1, Red 2
Blue 1
Red 1, Blue 1
Green 1, Blue 1
Red 1, Green 1, Blue 1
Red 2, Blue 1
Red 1, Red 2, Blue 1
Green 1, Red 2, Blue 1
Red 1, Green 1, Red 2, Blue 1
Red 3
Red 1, Red 3
Green 1, Red 3
Red 1, Green 1, Red 3
Red 2, Red 3
Red 1, Red 2, Red 3
Green 1, Red 2, Red 3
Red 1, Green 1, Red 2, Red 3
Blue 1, Red 3
Red 1, Blue 1, Red 3
Green 1, Blue 1, Red 3
Red 1, Green 1, Blue 1, Red 3
Red 2, Blue 1, Red 3
Red 1, Red 2, Blue 1, Red 3
Green 1, Red 2, Blue 1, Red 3
Red 1, Green 1, Red 2, Blue 1, Red 3
Red 1
Green 1
Red 2
Blue 1
Red 3
LED Cluster Diagram
