4-9
Routine Service and Maintenance
3. Change the hydraulic filter. See Service Manual and Figure 4–9 .
• The hydraulic filter will be filled with hydraulic fluid. Make sure to dispose of the
used hydraulic filter in an appropriate manner and according to State and Local
regulations.
• Make sure to dispose of the used hydraulic fluid in an appropriate manner and
according to State and Local regulations.
• Place a container under the upper hydraulic tank to capture any hydraulic fluid
that may drain out.
a. Remove the hydraulic filter (Item 2, Figure 4–9 ) from the filter mount (Item 1, Figure 4–
9 ) underneath the hydraulic tank.
b. Using a small amount of hydraulic oil, lubricate the rubber gasket on top of the new filter
canister and install the filter onto the filter mount.
Figure 4–9 Hydraulic Oil Filter
CAUTION
2
1
2448
