2-6
Operating Controls
7. Engine Choke – Moving the lever to the left sets the choke for easier cold engine starting
Moving the lever to the right opens the choke and allows the warmed up engine to run
properly.
8. Engine Throttle – Moving the control lever to the left increases the engine speed and
moving the lever to the right slows the engine to idle speed.
9. Keyswitch – Starts and stops the engine.
10. Trencher Activation "Operator Presence" Pedal – This pedal must be stepped on and
held in the downwards position before the trencher control lever is moved from the center
Neutral Lock position. When the operator presence control has be depressed, the trencher
activation control lever will be able to be moved into either the Forward or Reverse
position, activating the trencher chain. If the operator releases this control pedal, the
trencher hydraulic control lever will return to the Neutral position, stopping the trenching
operation.
7
8
9
10 2422
