6-12
2000-800-02 Motorized Loader
Using the Motorized Controller
(For Torque measurement only!)
The Motorized Control Loader consists of the Motorized Control Box
(MCB) and the Motorized Loader. The system is typically used in
conjunction with a Torque
Measurement Device, such as the 2000-810-01. The MCB controls the
motor to generate a force which is applied to a wrench while the 2000-
810-01 measures the resulting torque. When the target torque is
reached, the MCB will stops the motor.
The following is a step-by-step procedure to successfully operate the
Motorized Control Loader.
Note: Always check Emergency Stop to be on (by Pushing it in)
before switching the power on.
• Switch MCB Main Power ON ( switch is located at power
amplifier box).
• Switch ON Torque Tester (2000-810-01).
• Release Emergency Stop (E_STOP) Button (by Pulling it out).
· Switch ON MCB (by pressing Green System Control Button:
LED should light up).
Read this manual completely and carefully. Pay special
attention to all warnings, cautions, and safety rules. Failure
to follow the instructions may result in safety hazards
which could injure personnel or damage the control, motor
or other equipment.
