caso Vakuumierer VC220
39
13.2 Panel
A Indicator lamp for sealing
indicates the seal process
B Button Seal only
For sealing the bag without vacuum
C Stop
switches off the vacuuming and sealing action whenever the operator wants to stop the
operation
D Indicator lamp for vacuum
indicates the vacuum process
E Vacuum & Seal
draws air out of the bag and automatically changes operation to seal the bag after vacuum
is completed
F Indicator lamp for vacuum in canister
indicates the vacuum process
G Vacuum canister
- draws air out of the canister
- draws air from the zip bag with the vacuum hose (vacuuming).
13.3 Rating plate
The rating plate with the connection and performance data can be founded on the back of
the device.
A
B
D
E
F
G
C
