Salter Brecknell S100 User Manual
Page 13
Scale calibration
Calibration Configuration Settings –
The scale is configured from the factory to match the specified settings for each unit, as defined by the product
specifications and sales brochure. Modification of the setting can be accomplished by altering user configuration
settings P7-P10. Caution: Calibration and/or configuration of calibration settings of your scale should be
accomplished by a trained service technician using certified weights to ensure proper operation and accuracy.
Calibration is not covered under warranty.
Setup Controls
Config
Menu
Avail.
Settings
Default Definition
Detailed
Setting
P7 00-31
See table 2A
Displayed Resolution
(00) = 500 (08) = 2400 (15) = 7000
(01 )= 600 (09) = 2500 (16) = 7500
(02 )= 750 (10 )= 3000 (17) = 8000
(03 )= 800 (11) = 3500 (18) = 10,000
(04) =1000 (12 )= 4000 (19) = 12,000
(05 )=1200 (13) = 5000 (20) = 15,000
(06) =1500 (14) = 6000 (21-31) = N/A
(07) = 2000
P8 0,1,2
See table 2a
Division Increment
0 = 1 ; 1 = 2 ; 2 = 5
P9 0-5
See table 2a
Decimal Position
0 = 123456 ; 1 = 12345.6; 2 = 1234.56 ;
3 = 123.456 ; 4 = 12.3456 ; 5 = 1.23456
P10 0,
1
See table 2a
Calibration weight
0 = KG ; 1 = LB
Factory Calibration Settings shown in bold
Primary Capacity
Displayed Resolution
Units Selectable Capacity
P7
P8
P9
P10
150 lb x 0.02 lb
7500
75 kg x 0.01kg
16
1
2
1
150 x 0.05 lb
3000
10
2
2
1
150 x 0.1 lb
1500
06
0
1
1
300 lb x 0.05 lb
6000
150 kg x 0.02kg
14
2
2
1
300 x 0.1 lb
3000
10
0
1
1
300 x 0.2 lb
1500
06
1
1
1
600 lb x 0.1 lb
6000
300 kg x 0.05kg
14
0
1
1
600 x 0.2 lb
3000
10
1
1
1
600 x 0.5 lb
1200
05
2
1
1
75 kg x 0.01 kg
7500
150lb x 0.02lb
16
0
2
0
75 x 0.05 kg
1500
06
2
2
0
75 x 0.1 kg
750
02
0
1
0
150 kg x 0.02kg
7500
300lb x 0.05lb
16
1
2
0
150 x 0.05 kg
3000
10
2
2
0
150 x 0.1 kg
1500
06
0
1
0
300 kg x 0.05kg
6000
600lb x 0.1lb
14
2
2
0
300 x 0.1 kg
3000
10
0
1
0
300 kg x 0.2 kg
1500
06
1
1
0
Table 2a
You may choose to configure your scale for a higher resolution. The factory does not recommend increasing the
resolution above 7,500 divisions for a stable weight reading. Certain environments may cause the scale to be
unstable at factory settings, reduce the # of division settings to increase your stability.
Hold
kg
Moves flashing digit
Units
Change flashed digits
Tare
kg
Saves data and move down
to next Parameter setting
.
On/Off
Zero
Exits setup mode
