AVer Bullet Installation Guide - Manual (Page 19)

17
ENGLISH
Model FB2027-3 FB3027
Interface
Digital input/output 1/1
BNC Video output Yes
Built-in storage option Micro SDHC & SDXC card (64GB max.)
Built-in microphone N/A
External microphone input Yes
External Audio output Yes
General
Power supply DC 12V(2A)/PoE
Power consumption
PoE (TYP.):
6.4W (LED/Heater off)
10.6W (LED on, Heater off)
18.5W (LED off, Heater on)
19.7W (LED/Heater on)
DC-IN (TYP.):
4.6W (LED/Heater off)
8.2W (LED on, Heater off)
14.6W (LED off, Heater on)
15.7W (LED/Hearer on)
PoE PoE Class 4 (IEEE802.3at)
Dimensions
200 mm x 82.1 mm x 82.2 mm (L x H x W)
w/o bracket
Net weight 1110g
Temperature and humidity
-15°C~45°C, 20%~90% Cold Start
-25°C~45°C, 20%~90% Operating
IP Rating IP67
Software Requirement
OS Windows
®
XP/7/8
Browser IE 8/9/10 (Full Function), Chrome, Firefox and Safari (Basic Function)
Firmware remote upgrade Yes (via HTTP)
