15
ENGLISH
 FB2027-3/ FB3027
Model FB2027-3 FB3027
Lens spec. PTK-2M2812N14IR
Lens type vari-focal Lens (Board mount, M14)
F/no F1.4
Iris type DC Iris
Focal length 2.8~12mm
View Angle
H 97°(W)~28.7°(T)
V 61.2°(W)~21.6°(T)
Camera image
Min. illumination
1 Lux in day mode (IR off)
0.15 Lux in night (IR off)
0 Lux in night mode (IR on)
Built-in LED Yes
IR distance 30M
Built-in mechanical ICR Yes
Auto IRIS Yes
Video
Compression H.264/MPEG-4/MJPEG
Max. resolution 1920 x 1080 2048 x 1536
Frame rate 1920 x 1080 @ 30fps
2048 x 1536 @ 20fps
(Wide Angle)
1920 x 1080 @ 30fps
(Normal mode)
H.264/MPEG-4
bit rate mode
VBR, 5 levels
CBR, 64/128/512/768Kbps & 1/2/3/4/6/8/10/12Mbps
MJPEG quality 5 levels
Regional of Interest Yes
Smart Stream Yes, 5 windows
Image orientation mirror, flip
