11
ENGLISH
Technical Specifications

FB2027-1 / FB2027-2
Model FB2027-1 FB2027-2
Lens spec. PTN-2M4016IR PTN-2M6016IR
Lens type fixed focal Lens (Board Mount M12 P0.5)
F/no F1.6
Iris type Fixed
Focal length 4.0mm 6.0mm
View Angle
H 62.4°
V 46.5°
H 46.8°
V 34.7°
Camera image
Min. illumination
1 Lux in day mode (IR off)
0.15 Lux in night (IR off)
0 Lux in night mode (IR on)
Built-in LED Yes
IR distance 30M
Built-in mechanical ICR Yes
Auto IRIS Yes
Video
Compression H.264/MPEG-4/MJPEG
Max. resolution 1920 x 1080
Frame rate 1920 x 1080 @ 30fps
H.264/MPEG-4
bit rate mode
VBR, 5 levels
CBR, 64/128/512/768Kbps & 1/2/3/4/6/8/10/12Mbps
MJPEG quality 5 levels
Regional of Interest Yes
Smart Stream Yes, 5 windows
Image orientation mirror, flip
Motion Detection zones 3
Privacy mask areas 3
