AVer CM3000 for E5016 User Manual
Page 16
11
Name
Function
(2) E-map (F3)
Switch to display the map and show the location of the DVR server on
the map. If you are using a single monitor, press ESC to revert back to
the CMS main application( see also
(3) Monitor (F4)
Switch to display live video from the selected DVR servers group. If user
is using a single monitor, press ESC to revert back to the CMS main
application (see also
).
(4) Reset Alarm
The function doesn
’t support for E5016.
(5) MiniCenter Viewer
The function doesn
’t support for E5016.
(6) Network
Enable/disable the remote alarm data received. This is activated
automatically when the CMS software starts up.
(7) Setup
Configure the CMS system settings. Only the administrator is authorized
to access this command. (see also
(8) Playback
Select to playback video from the local hard disk or remote DVR server
(see also
).
(9) Alarm Center
The function doesn
’t support for E5016.
(10) DVR Status
To view all monitor DVRs
’ status – IP, CPU usage, Bandwidth usage,
HDD free space, Connection status, Video Loss status
….and so on.
(11) Status
Display the current date, and time
(12) Log extender
Expand and reduce the log viewer
(13) Log viewer
List the entire info in event mode or text mode from all DVR servers.
i
There are a few Hot keys for quick switching between the different applications or display
mode on a single monitor system.
-
F1: displays current DVR server information on the CMS Monitor screen.
-
F3: Switches to E-Map mode
-
F4: Switches to Monitor mode
-
Esc: Switches back to the CMS application main screen
