Network Quick Setup Guide
Note: Please pass this page to your Network Admin/IT Dept.
For more detailed instructions in setting up Admin Password/System Name and Phonebook,
please refer to the user manual CD or download the file from our website.
 Bandwidth Requirements
From the remote press “Home” -> “Setting” -> “System Settings” -> “Network”
Resolution Quality / Bandwidth MCU w/ 3 site*
4SIF (704x480)/4CIF (704x576) 256kbps/384kbps 768kbps/1152kbps
720p @ 30 frames per second
(1280x720)
1Mbps (Point to Point only)
(Example: If you plan to reserve 512k and not exceed 1Mbps for video conferencing then
leave above settings as default. For a specific entry in the phonebook with which you wish
to implement HD, you can set call quality to 1Mbps in the phonebook or while dialing.)
 AVer H-Series H.323 Related Port Usage for Firewall Setup
Port Function Type
1719 Gatekeeper UDP (Bi-Directional)
1720 H.323 Call setup TCP (Bi-Directional)
30000-30039
Signaling and control for audio, call,
video, and data/FECC
TCP and UDP
80 HTTP Interface (Web Tool)
5060 SIP TCP and UDP
Enable H.323 ALG (if applicable)
 Four Possible Setup Scenarios for Video Conferencing
(Please pick the scenario most suitable for your network environment)
1. Public IP Configuration (Outside of Firewall)
- Do you have a dedicated public IP address for the AVer H-Series System?
2. Private IP Configuration (Behind Firewall with Port Forwarding)
