Connect the power adapter to a standard 100V~240V AC power source.

Power adapter

Power cord

Wall outlet

C

C

o

o

n

n

n

n

e

e

c

c

t

t

i

i

n

n

g

g

a

a

T

T

V

V

Locate the VIDEO, S-VIDEO or SCART RGB input port of the TV or
Video equipment (i.e., VCR) to record your presentation on a videotape
and connect it to S-VIDEO or VIDEO OUTPUT port of CP150. If you are
not sure, please refer to the user manual of the TV or Video equipment.

For better video quality, we strongly suggest using S-VIDEO
connection.
Make sure the TV/RGB switch is set to TV.

S-Video cable

S-Video to SCART cable

(not supplied)

S-VIDEO

RCA to SCART cable

(not supplied)

RCA cable

VIDEO

SCART

SCART

I N P U T

P r o j e c t o r

Te l e v i s i o n

V C R
