ENGLISH
34
Function
Data[0]
Data[1]
Data[2]
CheckSum
Code
RS-232 Code
SPLITSCREEN
DIR: LOWER
SCREEN
0x26 0x02
0x00 0x7F
52,0B,03,26,02,00,53,7F
SPLITSCREEN
DIR: LEFT
SCREEN
0x26 0x03
0x00 0x7E
52,0B,03,26,03,00,53,7E
SPLITSCREEN
DIR: RIGHT
SCREEN
0x26 0x04
0x00 0x79
52,0B,03,26,04,00,53,79
RECORD: OFF
0x27
0x00
0x00
0x7C
52,0B,03,27,00,00,53,7C
RECORD: ON
0x27
0x01
0x00
0x7D
52,0B,03,27,01,00,53,7D
RECORD
FORMAT: MOV
0x28 0x00
0x00 0x73
52,0B,03,28,00,00,53,73
RECORD
FORMAT: AVI
0x28 0x01
0x00 0x72
52,0B,03,28,01,00,53,72
MOVIE FAST
REWIND
0x29 0x00
0x00 0x72
52,0B,03,29,00,00,53,72
MOVIE FAST
FORWARD
0x2A 0x00
0x00 0x71
52,0B,03,2A,00,00,53,71
MOVIE VOL
INC
0x2B 0x00
0x00 0x70
52,0B,03,2B,00,00,53,70
MOVIE VOL
DEC
0x2C 0x00
0x00 0x77
52,0B,03,2C,00,00,53,77
RECORD
QUALITY:
STANDARD
0x2D 0x00
0x00 0x76
52,0B,03,2D,00,00,53,76
RECORD
QUALITY: FINE
0x2D 0x01
0x00 0x77
52,0B,03,2D,01,00,53,77
RECORD
QUALITY:
FINEST
0x2D 0x02
0x00 0x74
52,0B,03,2D,02,00,53,74
STORAGE:
EMBEDDED
0x2E 0x00
0x00 0x75
52,0B,03,2E,00,00,53,75
STORAGE: SD
CARD
0x2E 0x01
0x00 0x74
52,0B,03,2E,01,00,53,74
STORAGE:
THUMB DRIVE
0x2E 0x02
0x00 0x77
52,0B,03,2E,02,00,53,77
FORMAT:
EMBEDDED
0x2F 0x00
0x00 0x74
52,0B,03,2F,00,00,53,74
FORMAT: SD
CARD
0x2F 0x01
0x00 0x75
52,0B,03,2F,01,00,53,75
OUTPUT
RESOLUTION:
1024x768
0x30 0x00
0x00 0x6B
52,0B,03,30,00,00,53,6B
OUTPUT
RESOLUTION:
1280x720
0x30 0x01
0x00 0x6A
52,0B,03,30,01,00,53,6A
