Connect an amplified speaker, Connect to a microscope – AVer M50(355AF) user manual User Manual
Page 16
ENGLISH
11
C
C
o
o
n
n
n
n
e
e
c
c
t
t
a
a
n
n
A
A
m
m
p
p
l
l
i
i
f
f
i
i
e
e
d
d
S
S
p
p
e
e
a
a
k
k
e
e
r
r
Plug a 3.5mm plug amplified speaker to port. Only the audio from the video playback is
supported.
We recommend connecting an amplified speaker to the Audio output port.
Take caution when using earphones. Adjust the volume down on the
remote to prevent hearing damage due to loudness.
Amplified Speaker
C
C
o
o
n
n
n
n
e
e
c
c
t
t
t
t
o
o
a
a
M
M
i
i
c
c
r
r
o
o
s
s
c
c
o
o
p
p
e
e
Connect the AVerVision M50 to a microscope enables you to examine microscopic objects
on a big screen.
1. Change the image display mode to Microscope. Press MENU > select MODE > select
MICROSCOPE and press ENTER.
2. Adjust the microscope and focus first. Then select the appropriate adapter size for the
microscope eyepiece.
3. Remove the microscope eyepiece from the microscope and connect it with the
microscope adapter. Fasten the 3 bolts until the adapter secures the eyepiece.
4. Attach the microscope adapter to the AVerVision camera head.
- Make sure to connect the longer hook to the front latch hole of the
camera head.
- For the eyepiece, we suggest using 15.5mm eye relief or higher.
Microscope
eyepiece
Microscope
Adapter
Microscope
2.5cm
2.2cm
