Alumax WA 40 User Manual
Page 8
INSTRUCTION MANUAL
8
FIXED PANEL ASSEMBLY
19
19
2
Assemble the
panel with the running rail. Align running rail holes with the holes of the
panel. Install glass fasteners(19) to
join the
panel(2) and the running rail (9). Be sure to place gaskets between all contact with glass and metal parts. Fasten with
hex 3mm key.
9
19
2
3
3a
Top View
3a
9
9
2
19
Side View
INTERIOR
SHOWER SIDE
19
9
2
