Tools and materials required – Alumax L-422 User Manual
Page 5
TOOLS AND MATERIALS REQUIRED
see page 13-14
see page 1 1-12
Support bar
Front panel
Corner clips
Bottom clips
2
Return panel
Bottom clips
see page 9-10
see page 16
Hinges
Door panel
see page 15
Side gasket
Door bottom
INSTALLATION MANUAL
PENCIL
DRILL
SILICONE
SCREWDRIVERS
CUTTING PLIER
LEVEL
TAPE MESURE
Ø1/4" & Ø1/8" DRILLBITS
MALLET
BLOCK
LONG NOSE LOCKING PLIER
2"
6"
1/2"
COMPONENTS
INSTALLATIONS OF
301X-24, 302X-24
