Alumax P-DR2W-72-CW - Manual (Page 2)

2
PARTS LISTING ........................................................ 3
PARTS TABLE .......................................................... 4
PROVIDED HARDWARE ............................................... 5
REQUIRED TOOLS AND MATERIALS ................................. 5
WALL JAMB INSTALLATION .......................................... 6
DOOR PANEL. ......................................................... 7
RETURN PANEL ........................................................ 7
RETURN PANEL (CONTINUED) ....................................... 8
RETURN PANEL (CONTINUED) ....................................... 9
FIXED PANEL .......................................................... 10
RUNNING RAIL ....................................................... 11
GLASS CLIPS .......................................................... 11
SMALL FIXED PANEL .................................................13
RUNNING RAIL ....................................................... 14
WALL BRACKET ...................................................... 15
DOOR PANEL ......................................................... 16
DOOR PANEL ......................................................... 16
STRAIGHT HANDLE .................................................. 17
DOOR PANEL SIDE GASKET ......................................... 18
STOPPERS ............................................................. 19
SILICONE .............................................................. 19
TABLE OF CONTENTS
GENERAL INSTRUCTIONS
- Read this manual carefully and completely before
proceeding.
- t c u d o r P are subject to change without no-
tice. Use the installation instructions supplied with the
product.
● WATERPROOFING
- No sealant is required inside the shower.
- All models are equipped with transparent sealing gaskets.
- For models with wall jambs, if your shower door is to be
installed over ceramic tiles, the tiles should lay completely
under the wall jambs.
● MAINTENANCE
- Never use scouring powder pads or sharp instruments on
metal pieces or glass panels.
- An occasional wiping down with a mild soap diluted in water
is all that is needed to keep the panels and aluminum parts
looking new.
- We recommend wiping the glass panels with a squeegee after
each use.
● SAFETY
- It is recommended that you wear safety glasses at all times
during the installation.
- At all times, 2 people are required for this installation.
