34
DXZ935
English 11. SPECIFICATIONS
FM Tuner
Frequency Range:
87.0 MHz to 108 MHz
Usable Sensitivity:
9 dBf
50dB Quieting Sensitivity:
15 dBf
Alternate Channel Selectivity:
70 dB
Stereo Separation (1 kHz):
35 dB
Frequency Response (±3 dB):
30 Hz to 15 kHz
AM Tuner
Frequency Range:
531 kHz to 1602 kHz
Usable Sensitivity:
25 µV
CD Player
System:
Compact disc digital audio system
Usable Discs:
Compact disc
Frequency Response (±1 dB):
5 Hz to 20 kHz
Signal to Noise Ratio (1 kHz):
100 dB
Dynamic Range (1 kHz):
96 dB
Harmonic Distortion:
0.01%
Audio
Maximum Power Output:
212 W (53 W
✕ 4 ch)
Continuous Average Power Output:
18 W
✕ 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
Bass Control Action (50 Hz):
±12dB
Treble Control Action (12.5 kHz):
±12 dB
Line Output Level (CD 1 kHz):
4 V/F 2ch + 4 V/R 2ch
4 V/NON-FADER 2ch
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable), negative
ground
Current Consumption:
Less than 15 A
Speaker Impedance:
4
Ω (4 Ω to 8 Ω allowable)
Weight / Source unit:
3.75 lb. (1.7 kg)
Weight / Remote control unit:
1 oz. (30 g) (including battery)
Dimensions / Source unit:
7" (Width)
✕ 2" (Height) ✕ 6-1/8" (Depth)
[178 (W)
✕ 50 (H) ✕ 155 (D) mm]
Dimensions / Remote control unit:
1-1/4" (Width)
✕ 2-3/16" (Height) ✕ 15/16"
(Depth)
[32 (W)
✕ 56 (H) ✕ 24 (D) mm]
Notes:
• Specifications and design are subject to change without notice for further improvement.
