PRESET EOCUSING- B
The focusing ring is fitted with a special ring for use when rapid refocusing to a specific
object distance is desired; the click-stop action of the ring enables operation “by touch”
for greater speed. To preset the lens, loosen the preset ring locking screw, rotate the
focusing ring as far as it will go in either direction, turn the focusing ring back to the
desired focus setting, and tighten the preset ring locking screw to set the click-stop
position.
DEPTH-OF-FIELD INDICATORS
Depth of field (i.e., the zone of acceptable image focus) can be checked by reading the
color-coded depth-of-field indicators engraved on the lens barrel. The pairs of colored
lines on either side of the white distance scale index line correspond to f/numbers of
the same color on the aperture scale. You can also observe the depth of field through
the viewfinder by simply pressing the depth-of-field preview button on the camera body.
FILTERS--------------------------------------------------------------------------------------------C
The Nikkor ED 1200mm f/11 IF uses standard Nikon 39mm screw-in filters mounted
on a filter holder which is inserted into the body of the lens just behind the tripod
mounting collar. To gain access to the filter holder for filter changing, press and turn
the knob on the filter holder 90° counterclockwise until the white line on the knob is
at right angles to the axis of the lens. The filter holder will come free and can be lifted
out of the lens. Unscrew the filter and replace it with the one you wish to use. Lock
the filter holder back in place by reversing the above procedure. A special filter holder
is provided with this lens which accepts gelatine filters. To fit the filter, release the
catch, nip open the filter plates, insert the gelatine filter, close the plates and cut off
the excess with a sharp knife. The filter holder can then be mounted in the usual way.
Please note that due to a slight difference in thickness between gelatine and glass filters,
some focus shift may occur when changing from one type of filter to the other; this
discrepancy is easily corrected, however, by slightly shifting the focus setting. A filter
must be mounted in the lens at all times.
RECOMMENDED FOCUSING SCREENS
Various interchangeable focusing screens are available for F2 and F3 Nikon cameras to
suit any type of lens or picture-taking situation. Those which are recommended for use
with this Nikkor ED 1200mm f/11 IF lens are listed below.
Screen
Camera —^
A L B
c
D E G1 G2 G3 G4 HI H2 H3 H4 J K P M R T
F 3 @ $ @ @ O @ s s m
F 2 O S' @ © © s •
I When the Teleconverter TC-200 is attached to this lens, use the following table*;
——___ Screen
Camera ^^
A L B
c
D E G1 G2 G3 G4 HI H2 H3 H4 J K P M R
T
F 3
f;
@ O o © # ® ®
F 2 -Vi
©
-V o o
©
- V “14
®
-V
*Vignetting or other performance deterioration may be noticeable in the image re­
corded on the film.
